Eaton easyE4 Control Relay with easySoft
The smart relay for small machines, HVAC, pumps and cold rooms: easyE4 hardware, easySoft in LD, FBD, ST and EDP, system settings, Ethernet, function blocks, user function blocks, PID and PWM, touch displays, SmartWire-DT, Modbus RTU, MQTT and AWS, and the data logger.
What you will learn
Explain where an easyE4 fits, program in LD, FBD, ST and EDP, set system functions and connect over Ethernet, use function blocks including user blocks, PID and PWM, connect displays, communicate over SmartWire-DT, Modbus RTU, MQTT and AWS, and log data.
- Know control relays, the easyE4 range and its features
- Install easySoft and program in LD, FBD, ST and EDP
- Set system functions and connect over Ethernet
- Use function blocks, user function blocks, PID and PWM
- Connect remote touch displays and XV panels and build visualisation
- Communicate over SmartWire-DT, Modbus RTU, MQTT and AWS
- Log data with the ring-buffer data logger and apply easyE4 to cold rooms
Course content
8 modules · 40 lessons · 5h 23m
In order, at whatever pace suits you. Each module ends with a practice task that builds on the last, and a short quiz.
- 01easyE4 and Control Relays10 lessons44m
- 02easySoft: Install, Licensing and Languages7 lessons31m
- 03System Settings and Ethernet3 lessons27m
- 04Function Blocks, User Blocks, PID and PWM6 lessons1h 4m
- 05Displays and Visualisation4 lessons1h 10m
- 06Communication: SmartWire-DT, Modbus RTU, MQTT and AWS5 lessons55m
- 07Data Logger and Applications4 lessons34m
- 08Final Assessment1 lesson2m
Requirements
- Who it is for
- Beginner. No PLC experience needed.
- Software
- easySoft 8 (free; simulation needs no licence)
- Hardware
- None required.
Eaton easyE4 Control Relay with easySoft at a glance
Eaton easyE4 Control Relay with easySoft is a free, self-paced online plc programming course from EDWartens India with 8 modules, 5h 23m of video lessons, written notes, practice tasks and assessments, and an optional verifiable certificate.
- Price
- ₹0, free for good. No trial, no card.
- Format
- 8 self-paced modules, 5h 23m of video, written notes, a quiz per module and a final assessment.
- Level
- Beginner. Beginner. No PLC experience needed.
- Brand
- Vendor-neutral
- Software
- easySoft 8 (free; simulation needs no licence)
- Hardware
- None required.
- Certificate
- Optional EDWartens Certificate of Completion, ₹700, verifiable by code. Not a vendor credential.
- Video lessons by
- Eaton (independent creators, credited below)
- Language
- English
A shareable EDWartens certificate
Finish every module and pass the final assessment, and you can buy a certificate for ₹700. It carries a unique verification code on a public page anyone can check, so it stands up when a recruiter looks it up.
- Add it to your LinkedIn profile in one click
- Link it from a CV or portfolio, the URL is permanent
- Publicly verifiable by code, not a PDF anyone can edit
- Issued by EDWartens India, the training centre itself
The course itself stays free whether or not you ever buy one.
Stuck? Ask a practising engineer
A free course usually means a comment section and hope. This one does not. Every module has an Ask-your-trainer panel that reaches the same engineers who teach our paid programme: people who commission panels for a living, not moderators.
- Questions answered in the context of the module you are on
- The same engineers who teach the AEP programme
- Career tools, CV help and public job listings included
- Your progress and notes stay in your account for good
Pairs well with
PLC programming · FreeSiemens TIA PortalFrom zero electrical knowledge to a working, simulated S7-1200 program, for nothing.
PLC programming · FreeSiemens S7-300 with STEP 7The classic Siemens PLC, from an empty SIMATIC Manager project to a commissioned, diagnosed, running machine.
PLC programming · FreeAllen-Bradley Studio 5000CompactLogix and ControlLogix from the wiring up: tags, instructions, timers, data, drives, messaging and Modbus, in Rockwell's Studio 5000.
PLC programming · FreeAllen-Bradley RSLogix 500 and MicroLogixThe MicroLogix and SLC 500 on real hardware: file-based addressing, every instruction group, analog scaling, faults and forces, in RSLogix 500.Common questions
Is easySoft free?
Yes to download and simulate; a licence is needed only to download to a physical easyE4.
easyE4 or Siemens LOGO!?
Both are control relays for small tasks; easyE4 adds SmartWire-DT, more expansion and cloud connectivity. The free LOGO! course covers the other one.
Are all lessons official?
Yes, all from Eaton's English channel.
Is the course really free?
Yes. Every module, practice task and assessment. You create an account so your progress is saved and the assessments can be marked. The certificate is the only paid item, and only if you want it.
What certificate do I get, and is it an Eaton qualification?
An EDWartens Certificate of Completion, issued when you pass the final assessment, with a verification code anyone can check. It is not an Eaton credential and is never described as one.
Who made the video lessons?
The creators named in the Credits block at the foot of this page, on their own YouTube channels. EDWartens did not make the videos and the creators are not affiliated with EDWartens. What EDWartens wrote is the study plan, the notes, the practice tasks and the assessments.
